Fein KBC36 MAGFORCE 1200W 36mm Compact Mag Drill

The Fein KBC 36 MAGFORCE magnetic drill is extremely powerful and robust for performing heavy-duty applications. It's also the most compact core drilling machine in the world for use in the tightest work situations. Overall, it's an excellent all-rounder that allows you to master difficult tasks with confidence.

• Carry case
• Lashing strap
• Additional handle
• Contact guard
• Coolant pump
• Swarf hook
• 1/2" ratchet
• 1/2" socket wrench extension
• 5mm hex socket wrench
• 5mm hex socket wrench with T-handle
• 82mm centring pin

• Maximum versatility for flexible working:
  • Universal tool for core drilling, twist drilling, reaming, countersinking and tapping
  • Designed for both industry and trade use
  • Great 36 mm core drilling capacity
  • Variable speed control
  • Reversible rotation
• Very powerful 1200 W motor for continuously fast work progress
• The most compact core drilling machine in the world, plus low weight for excellent mobility and flexibility, even in the tightest work situations
• Brushless motor for maximum performance and efficiency, plus a longer service life (completely maintenance-free)
• Tacho electronics for high speed stability
• Extremely robust and wear-resistant design that has been tried and tested in continuous use for high durability and a long life
• Strong 10,000 N magnetic holding force with a convenient holding force display
• High gear position and large installation space under the drill spindle provides a clear view of the drilling site at all times for complete control
• Spindle sleeve feed without clearance for accurate drilling
• Intuitive operating concept avoids mix-ups and can be clearly seen by the user
• Tilt sensor stops the motor if this Fein mag drill tilts or slips
• Personal safety switch for increased safety
• Speed-saving memory function
• Space-saving operation on both sides with the ratchet
• Integrated handle
• Combined drive shaft: 1/2" square and 8mm hex socket
• Slot for 5mm hex socket wrench on the tool itself

• Voltage: 110 V
• Core drill holder: 3/4 " weldon
• Max. carbide core drill diameter: 36 mm
• Max. core drill drilling depth: 35 mm
• Max. HSS core drill diameter: 36 mm
• Max. twist drill diameter: 16 mm
• Max. countersinking diameter: 32 mm
• Tapping: M12
• Stroke: 46 mm
• Input: 1200 W
• Output: 680 W
• No load speed: 130-660 rpm
  Full load speed: 130-610 rpm
• Magnetic holding power: 10000 N
• Magnetic foot dimensions: 175 x 80 mm
• Dimensions (L x W x H): 290 x 40 x 169 mm
• Weight: 8.5 kg
• Vibration: < 2.5 m/s²
• Sound pressure: 93.3 dB
  Sound power: 103.3 dB
  Sound peak: 106.3 dB
• Cable length: 3 m
• Part number: 72732361241

FEIN offer a standard 1 year warranty for commercial use or 2 year warranty for end consumers with all of their machines, batteries and chargers. You can extend this to a 3 year warranty by registering your product here within 3 months of purchase (excludes high-frequency power tools, AccuTec screwdrivers, balancers, pipe processing tools, compressed air tools, NiCd or NiMH batteries, and NiCd or NiMH chargers).

Note: Due to the nature of their application, accessories and consumables don't have a wear and tear guarantee or warranty. If you're unhappy with your product then you can contact FEIN directly to discuss this.
