Fein KBU35PQW 1010W 35mm Mag Drill with Permanent Magnet

The Fein KBU 35 PQW magnetic drill (110V) is a universal tool that can be used for core drilling, twist drilling, reaming, countersinking and tapping. It's powerful and robust for performing both industry and trade applications. It has a great 35 mm core drilling capacity and an extra-large 260 mm stroke range. It also has a permanent magnet for very safe working at heights.

• Carry case
• Lashing strap
• Contact guard
• Coolant tank
• Swarf hook
• Centring pin

• Maximum functionality for flexible working:
  • Universal tool for core drilling, twist drilling, reaming, countersinking and tapping
  • Designed for both industry and trade use
  • Great 35 mm core drilling capacity
  • Extra-large 260 mm stroke range
  • Variable speed control
  • Reversible rotation
  • Ability to work on curved surfaces without the need for an additional V-plate
• High torque for continuously good work progress
• High-power 1010 W motor for reliable working performance
• Perfect power-to-weight ratio thanks to the compact, weight-optimised design
• Tacho electronics for high speed stability
• Extremely robust with a high-quality tool design and a swivel-mounted motor cable protective hose for high durability in tough industry and trade use
• Extra-narrow permanent magnet with high 9,000 N magnetic holding force and convenient holding force display. The permanent magnet isn't powered by the tool's corded power for very safe working at heights. Magnetic bias provides 50% magnetic hold for easy positioning before full 100% hold for drilling.
• Simple operating concept with clear touch pad controls avoids mix-ups and can be clearly seen by the user
• Tilt sensor stops the motor if this Fein mag drill tilts or slips
• Personal safety switch for increased safety
• Speed-saving memory function
• QuickIN weldon fitting for tool-free core cutter changes
• Integrated coolant tank
• The feed handwheel can be moved from one side to the other

• Voltage: 110 V
• Core drill holder: 3/4 " weldon
• Max. carbide core drill diameter: 35 mm

• Max. core drill drilling depth: 50 mm
• Max. HSS core drill diameter: 35 mm
• Max. twist drill diameter: 16 mm
• Max. reaming diameter: 16 mm
• Max. countersinking diameter: 31 mm
• Tapping: M14
• Stroke: 135 mm
• Total stroke range: 260 mm
• Input: 1010 W
• Output: 550 W
• Full load speed: 130-520 rpm
• Magnetic holding power: 9000 N
• Magnetic foot dimensions: 195 x 70 mm
• Weight: 12.5 kg
• Vibration: < 2.5 m/s²
• Sound pressure: 86.7 dB
  Sound power: 97.7 dB
  Sound peak: 101.2 dB
• Cable length: 4 m
• Part number: 72707261240

FEIN offer a standard 1 year warranty for commercial use or 2 year warranty for end consumers with all of their machines, batteries and chargers. You can extend this to a 3 year warranty by registering your product here within 3 months of purchase (excludes high-frequency power tools, AccuTec screwdrivers, balancers, pipe processing tools, compressed air tools, NiCd or NiMH batteries, and NiCd or NiMH chargers).

Note: Due to the nature of their application, accessories and consumables don't have a wear and tear guarantee or warranty. If you're unhappy with your product then you can contact FEIN directly to discuss this.
